Description
Klüber Klübersynth GH 6-1000 is a synthetic high-performance gear (CLP PG 1000) and high-temperature oil with KlüberComp Lube Technology
- Based on polyglycol satisfying the growing requirements and increasing power density of modern gears.
- It includes KlüberComp Lube Technology*, i.e. it is based on especially high-grade raw materials and advanced additives, enabling maximum performance in the lubrication of all gear components.
- Pack Size: Canister 5l (Manufacturer n°: 0121650764)
- Also available in: canister 20l, Drum 200l
Benefits for your application
- High scuffing protection
- Excellent wear protection for gears and rolling bearings
- Good shear stability for reliable lubricant film formation
- High micropitting resistance
- Optimised for the lubrication of worm gears
- Excellent ageing and oxidation resistance
- Wide service temperature range due to good viscosity-temperature behaviour
- Low foaming tendency
- Energy savings due to optimised friction behaviour
- Good elastomer compatibility
- Approvals by numerous gear OEMs
Application
- Klübersynth GH 6 oil was especially developed for the lubrication of worm gears with steel/bronze or steel/grey cast iron pairings.
- Klübersynth GH 6 oil is also used for the lubrication of bevel and spur gears, rolling and plain bearings as well as all types of toothed couplings, especially when exposed to high temperatures.
- It can also be used for the lubrication of lifting, drive and transport chains.
Application notes
- Klübersynth GH 6 can be applied by means of immersion, immersion circulation or injection.
- The use of drip-feed oilers, brushes, oil cans or suitable automatic lubricating systems is also possible.
- When using automatic lubricating systems, please note the manufacturer’s instructions regarding the maximum permissible viscosity.
- The low-viscosity varieties are also used for oil mist lubrication.
Technical specifications
| Article number | 012165 |
| Labeling according to DIN 51502 | CLP PG 1000 |
| Labeling according to ISO 12925-1 | CKC 1000 |
| Lower service temperature | -25 °C / -13 °F |
| Upper service temperature | 160 °C / 320 °F |
| ISO viscosity grade, DIN ISO 3448 | 1000 |
| Density, based on DIN 51757) at 15 °C | approx. 1 075 kg/m³ |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 20 °C | approx. 3 000 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 1 000 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 167 mm²/s |
| Viscosity index, DIN ISO 2909 | >= 260 |
| Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus | >= 250 °C |
| Pour point, DIN ISO 3016 | <= -25 °C |
Hazard Warnings (CLP)
Signal word: None
Hazard Statements (H-phrases)
- H412: Harmful to aquatic life with long-lasting effects.
Safety Statements (P-phrases)
Prevention:
- P273: Avoid release to the environment.
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
