Klübersynth GE 14-111 Special grease for small gears 180kg

Speciality greases for small gears operating under heavy loads and with a high percentage of sliding friction.

Do you need to design small, grease-lubricated gearboxes that are both efficient and powerful? Does increasing power density pose an additional challenge? If so, you will probably also have to observe a wide service temperature range as well as excellent wear protection. Our Klübersynth GE 14-111 special greases are the right solution for such tasks.
Based on our many years of experience, we have developed these speciality greases consisting of synthetic hydrocarbons, ester oil and an aluminium complex soap thickener. With their precisely tuned additives and the solid lubricants contained, the products offer excellent wear protection over a wide service temperature range. We are pleased to discuss application details with you.

Your benefits at a glance:

• Excellent wear protection and high pressure absorption capacity
• Reliable lubricant film formation in a wide service temperature range
• Excellent protection against tribo-corrosion
• High scuffing-load strength with minimum-quantity lubrication

Application:
You may use Klübersynth GE 14-111 for the lubrication of gears, bearings, joints or slideways in small gears that are subject to heavy leads, e.g. in household  or workshop power tools. Due to its good scuffing load strength and backflow characteristics, Klübersynth GE 111 can also be applied in toothed gears with a  high percentage of sliding friction. Depending on temperature, loads and sliding speeds, steel/steel, steel/aluminium and aluminium/aluminium combinations can be lubricated with these greases.
Additionally, Klübersynth GE 14-111 offer smooth running and excellent wear protection when used for lubricating trapezoidal spindles.

Application notes:
Klübersynth GE 14-111 are supplied ready for use. They can be applied using a spatula, brush or grease gun. Lowcost application with fully automatic standard (micro) metering systems is also possible. Please note, however, that due to different system configurations and application conditions the pumpability of the products has to be confirmed.
We will be glad to support you with application-specific advice.

Product data:

Article number	012253
Chemical composition	solid lubricant
Chemical composition, thickener	aluminium complex soap
Chemical composition, type of oil	ester oil
Chemical composition, type of oil	synthetic hydrocarbon oil
Lower service temperature	-55 °C / -67 °F
Upper service temperature	140 °C / 284 °F
Color space	yellow
Texture	fibrous
Texture	homogeneous
Worked penetration, DIN ISO 2137, 25 °C, lower limit value	320 x 0.1 mm
Worked penetration, DIN ISO 2137, 25 °C, upper limit value	360 x 0.1 mm
Shear viscosity at 25 °C, shear rate 300 s-1; equipment: rotational viscometer	approx. 3 000 mPas
Drop point, DIN ISO 2176, IP 396	>= 200 °C
Anti-brinelling test, acc. to SNR FEB 2, frequency 24 Hz, deflection 3, load 8000 N,  50 h at 25 °C, wear	<= 5 mg
Flow pressure of lubricating greases, DIN 51805, test temperature: -55 °C	<= 1 400 mbar
Four-ball tester, welding load, DIN 51350 pt. 04	>= 4 000 N
Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the  unopened original container, approx.	12 months



Information on product safety (Manufacturer, Contact)

KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
