Description
Klübersynth CHM 2-220 High-temperature oils for transmission, lifting and conveyor chains
- The high-temperature oils of the Klübersynth CHM 2 series are manufactured on the basis of ester mixtures.
- These fully synthetic oils show good wear protection, low formation of residues (which are soluble in fresh oil) and high thermal stability.
- Their high lubricity increase operational reliability and extend the service life of machines.
- Temperature range: -5°C to +250°C
- Volume: Canister 20 l
- Also available in: Canister 5 l, Drum 200 l
Benefits for your application
- Cleaner chains due to lower residue formation
- Low evaporation rates resulting in lower consumption
- Low maintenance costs, as residues are soluble in fresh oil
- Reduced investment and repair costs due to extended chain life
- Low friction values reduce power consumption and CO2 emission liability
Applications
- Klübersynth CHM 2 oils are suitable for transmission, lifting and conveyor chains up to approx. 250 °C in the following industries:
- Conveyors – e.g. surface coating, metal coating, white goods, furniture
- Drying installations – e.g. rock wool or gypsum board manufacture
Application notes
- Klübersynth CHM 2 oils can be applied by means of commercial lubricating equipment.
- In case of contact with elastomers and plastics their resistance to Klübersynth CHM 2 oils should be checked.
Technical specifications
| Article number | 002170 |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Chemical composition, type of oil | ester oil |
| Lower service temperature | -5 °C / 23 °F |
| Upper service temperature | 250 °C / 482 °F |
| Colour space | yellow |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 220 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 22 mm²/s |
| Viscosity index, DIN ISO 2909 | >= 115 |
| Density, DIN 51757, 20 °C | approx. 0.95 g/cm³ |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
