Description
Klüberrail AL 32-2000 Sprayable, rapidly biodegradable lubricant for railway switches | N° 009020
- Long relubrication intervals are particularly important for the lubrication of railway switches where reliable equipment function is to be ensured in a less labour-intensive way. Klüberrail AL 32-2000 is a synthetic, rapidly biodegradable special lubricant for railway switches. It meets the requirements of the OECD 301 F test for biodegradability (> 60 % after 10 days).
- Due to its liquid texture, the lubricant can be sprayed by means of portable lubrication equipment, enabling an extremely good and economical distribution. As Klüberrail AL 32 2000 offers good wear protection and is resistant to washout by rain, lubrication intervals can be extended.
- The product is effectively protected against UV light, which prevents rapid gumming in sunlight and hence an increase of switch setting forces.
- Temperature range: -35°C to +80°C
- Volume: 10l canister
Benefits for your application
- Trouble-free operation due to low friction resistance also at very low ambient temperatures
- Good UV resistance prevents rapid gumming of the applied lubricant after long exposure to sunlight
- Less cleaning and maintenance required as lubricant forms no grease collar in switch end positions
- Sprayable by means of standard portable spraying equipment or in the form of Klüberrail AL 32-2000 Spray
- Low operating costs due to considerably lower lubricant consumption and less manpower for relubrication
- Eco-compatible due to rapid biodegradability
Applications
- Klüberrail AL 32-2000 was developed for the lubrication of railway switch slide plates where it might drip off and pose a hazard to the environment.
- In addition, Klüberrail AL 32-2000 is intended for applications requiring a rapidly biodegradable lubricant with a liquid texture, for example on slideways or chains.
Application notes
- Klüberrail AL 32-2000 is applied by spraying equipment or brush. Application via portable spraying devices is also possible at temperatures below 0 °C. Avoid mixture with water when filling the product. Relubrication intervals depend on ambient conditions, rain/snow and the frequency with which the switches are set.
Technical specifications
| Lower service temperature | -35 °C / -31 °F |
| Upper service temperature | 80 °C / 176 °F |
| Colour space | brown |
| Texture | liquid |
| Runout time, DIN EN ISO 2431, with flow cups, 5 mm nozzle | approx. 60 s |
| Density at 20 °C | approx. 0.96 g/cm³ |
| Four-ball tester, wear factor, DIN 51350 pt. 05, 1 h/400 N, wear scar diameter | <= 0.6 mm |
| Biodegradability according to OECD 301 F, (within 28 days) | >= 60 % |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
