Description
Special lubricating grease for plain bearings
- Service temperature range: -40°C to +140°C
- semi-synthetic long-term grease
- high pressure absorption capacity at low speeds
- good adhesion on the component and resistance to aggressive media
- enhance wear protection
- Composition: barium complex soap, synthetic hydrocarbon oil, mineral oil
- Colour: beige
- Size: 1kg can
- also available as: bucket: 25kg
Benefits for your application
- Less maintenance due to long-term lubrication
- Reliable function and sealing against dust and dirt
- Versatile application even under high loads and low speeds
- Long component life due to high wear and corrosion protection
- Tried and tested for many bronze plain bearings, good compatibility with nonferrous metals
- Also suitable for relubrication; miscible with many commercial bearing greases
Application
- lubrication of bronze plain bearings, e.g. Wieland-B09 (CuSn8)
- sliding elements and plain bearing bushes subject to low sliding speeds or oscillations in the mixed friction regime
- joints and self-aligning bearings in building machines or agricultural and forestry vehicles
- rolling bearings subject to high loads and speeds up to approx. 100,000 mm/min
Technical Specifications
| Chemical composition, thickener | barium complex soap |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Chemical composition, type of oil | mineral oil |
| Lower service temperature | -40 °C / -40 °F |
| Upper service temperature | 140 °C / 284 °F |
| Colour space | beige |
| Density at 20 °C | approx. 0.93 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 310 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 340 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 500 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 43 mm²/s |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 8 000 mPas |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 4 000 mPas |
| Drop point, DIN ISO 2176, IP 396 | >= 220 °C |
| Flow pressure of lubricating greases, DIN 51805, test temperature: -40 °C | <= 1 400 mbar |
| Minimum shelf life from the original container, approx | 36 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
