Description
Klüberplex GE 11-680 Adhesive gear lubricant
- Klüberplex GE 11-680 is an adhesive lubricant with a mineral oil base and an aluminium complex soap thickener.
- It is resistant to high pressure and contains anti-wear additives, corrosion and oxidation inhibitors.
- Klüberplex GE 11-680 is free of bitumen, solvents and raw materials containing lead.
- Temperature range: 0°C to +140°C
- Volume: 400g cartridge
- Also available in: in 1 Kg can, and in STAR 60cm³ cartridge
Benefits for your application
- Adhesive lubricant
- Free of raw materials containing lead or solvents
- Resistant to high pressures
- FZG scuffing load stage > 12
- Anticorrosion properties
- Applicable through automatic lubrication systems
Applications
- Klüberplex GE 11-680 is designed for the lubrication of open and closed spur and bevel gears, lifting spindles, slideways and guideways, large chain drives and sliding bearings.
- It is particularly suitable for elevated component temperatures and wherever adhesive lubricants containing solid lubricants should not be used.
Application notes
- Klüberplex GE 11-680 should preferably be used for the lubrication of tooth flanks. It is applied to the gears through automatic spray systems. Smaller drives are also lubricated through positive drip-feed equipment, by brush or a hand spray equipment (e. g. with the Klübermatic LB spray gun). Splash lubrication is possible for components operating at low circumferential speeds (< 3 m/s).
Technical specifications
| Chemical composition, thickener | aluminium complex soap |
| Chemical composition, type of oil | mineral oil |
| Lower service temperature | 0 °C / 32 °F |
| Upper service temperature | 140 °C / 284 °F |
| Colour space | brown |
| Texture | very soft |
| Density at 20 °C | approx. 0.94 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 380 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 420 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 685 mm²/s |
Klüberplex GE11-680, Klüberplex GE11680
Hazard Information (CLP)
Signal word: Warning.
Hazard statements (H-statements)
- H317 May cause an allergic skin reaction.
Precautionary statements (P-statements)
General:
- P101 If medical advice is needed, have product container or label at hand.
- P102 Keep out of reach of children.
- P103 Read carefully and follow all instructions.
Prevention:
- P280 Wear protective gloves and protective clothing.
- P261 Avoid breathing mist / vapour / aerosol.
- P272 Contaminated work clothing should not be allowed out of the workplace.
Response:
- P302+P352 IF ON SKIN: Wash with plenty of water and soap.
- P333+P313 If skin irritation or rash occurs: Get medical advice/attention.
- P362+P364 Take off contaminated clothing and wash it before reuse.
Disposal:
- P501 Dispose of contents/container to an approved hazardous waste disposal site in accordance with local regulations.
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
