Description
Klüberplex BEM 34-131 N Speciality rolling bearing grease for demanding applications
- For the lubrication of your wind turbine generators, you are interested in increasing the service life of the rolling bearings and extending the service intervals.
- With Klüberplex BEM 34-131 N, we offer them a long-life grease that has an increased load-carrying capacity, and very good wear protection as well as excellent corrosion protection even when their equipment is not in operation.
- Klüberplex BEM 34-131 N also allows longer grease service lives and can be used in various lubrication systems.
- Volume: 400g cartridge
- Also available as: 1kg can, 25kg bucket, 180kg drum
Benefits for your application
- Increased reliability of wind turbine generators due to excellent corrosion protection, good resistance to weather and a wide service temperature range
- Longer service life of rolling bearings due to good wear protection, also under vibration and oscillation
- Reliable operation due to good pumpability and metering via centralised lubrication systems
- Low frictional resistance, reduced wear and component temperature due to excellent lubricity
Application
- Klüberplex BEM 34-131 N is used for the lubrication of generator bearings in wind turbines. It can also be used for rolling bearings subject to oscillation, high loads and vibration.
- Klüberplex BEM 34-131 N is a grease for long-term or lifetime lubrication of different rolling bearing types and applications subject to various operating conditions. These may be found in: Hub units (wheel bearings in cars), shock absorber bearings, fans, electric motors, water pumps, paper-making machines (wet-processing zone), conveyors, universal joint bushes, linear guides and ball screws subject to micro movement.
Technical specifications
| Article number | 017181 |
| Lubricating greases -K, DIN 51825 in connection with DIN 51502 | KPHC1N-30L |
| Chemical composition, type of oil | mineral oil |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Chemical composition, thickener | calcium complex soap |
| Lower service temperature | -35 °C / -31 °F |
| Upper service temperature | 150 °C / 302 °F |
| Colour space | yellow |
| Density at 20 °C | approx. 0.90 g/cm³ |
| NLGI grade, DIN 51818 | 1 |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 134 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 16 mm²/s |
| Low-temperature torque, IP 186, -35 °C, running | <= 100 mNm |
| Low-temperature torque, IP 186, -35 °C, start | <= 1 000 mNm |
| Drop point, DIN ISO 2176, IP 396 | >= 220 °C |
| Flow pressure of lubricating greases, DIN 51805-2, test temperature: -30 °C | <= 1 400 mbar |
| Speed factor (n x dm) | approx. 1 000 000 mm/min |
| Testing of lubricating greases on FAG FE9 rolling bearing tester, DIN 51821 pt. 02, speed: 6000 min-1, axial load: 1500 N, temperature: 150 °C, service life F50: | >= 100 h |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 36 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
