Description
Klüberoil 4 UH1-150 N Synthetic gear and multipurpose oil for the food-processing and pharmaceutical industries | N° 029041
- Klüberoil 4 UH1 N is a synthetic high-performance gear and multipurpose oil based on polyalphaolefin satisfying the growing requirements and increasing power density of modern gears.
- Klüberoil 4 UH1 N is based on high-grade raw materials and advanced additives, enabling maximum performance in the lubrication of all gear components.
- Volume: 20l canister
- Also available in: 1l canister , 5l canister, 200l drum
Benefits for your application
- Registered as NSF H1 and certified according to ISO 21469
- High scuffing protection
- Good wear protection for gears and rolling bearings
- Good shear stability for reliable lubricant film formation
- Excellent ageing and oxidation resistance
- Wide service temperature range due to good viscosity-temperature behaviour
- Low foaming tendency
- Energy savings due to optimised friction behaviour
- Good elastomer compatibility
- Approved by numerous gear OEMs
Application
- Klüberoil 4 UH1 N was developed for the lubrication of spur, bevel and worm gears subject to high loads, bearings, spindles, joints as well as lifting, drive and transport chains.
Application notes
- Klüberoil 4 UH1 N can be used for immersion, immersion circulation and injection lubrication.
- The use of drip-feed oilers, brushes, oil cans or suitable automatic lubricating systems is also possible.
- When using automatic lubricating systems, please note the manufacturer’s instructions regarding the maximum permissible viscosity. The low-viscosity varieties are also used for oil mist lubrication.
Technical specifications
| Upper service temperature | 120 °C / 248 °F |
| Density, based on DIN 51757) at 15 °C | approx. 858 kg/m³ |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 150 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 19 mm²/s |
| ISO viscosity grade, DIN ISO 3448 | 150 |
| Viscosity index, DIN ISO 2909 | >= 140 |
| Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus | >= 200 °C |
| Pour point, DIN ISO 3016 | <= -36 °C |
| Ageing properties, ASTM D 2893, increase in viscosity | <= 6 % |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx | 36 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
