Klübermatic KD hand sprayer

• Low investment costs
• High reliability
• Easy handling – no special training required for operation
• High flexibility – shoulder strap provided for ease of transport (weight with complete fill: approx. 11 kg)
• Corrosion-resistant materials – long equipment life
• Not subject to EC pressure equipment – no regular pressure inspection required sure equipment directive

Description

• The manual spraying equipment comprises a stainless steel reservoir and a hand pump used to build up a compressed air
• cushion above the lubricant level up to a maximum operating pressure of 6 bar.
• In addition to the standard spraying tube of 450 mm with a bent nozzle end, an extension tube is provided that can be
• continuously adjusted from 1070 to 2000 mm. The usability of the equipment has been tested, and it has been adjusted to the
• requirements in practice. It does not require a stationary compressed air connection. Klübermatic KD is TÜV and GS certified.

Application

• Klübermatic KD is primarily used for loose kiln riding rings lubricated with WOLFRACOAT C FLUID.

Application notes

• The built-in air pump is screwed out anti-clockwise to fill the pressure vessel.
• Caution: Prior to filling, the lubricant container should be well shaken to activate the solid lubricants.
• When the pressure vessel has been filled with lubricant (5 l max.), the air pump is fitted again and screwed fast to ensure an air-tight seat.
• For safety during transport, the air pump handle can be locked.
• Do not screw fast too tight to facilitate release when activating the pump.
• The pump is used to build up a compressed air cushion. The maximum permissible pressure is 6 bar, which can be checked
• on the pressure gauge, red mark. Upon pumping, Klübermatic KD is ready for use.
• The lubricant jet is activated by brief actuation of the hand valve.
• The jet nozzle is directed onto the friction point, i.e. the inside of the kiln riding ring.
• If the pressure inside the pressure vessel exceeds 6 bar, the safety relief valve must open automatically.
• To relieve the pressure manually – e.g. when the pump is to be dismounted for refilling — open the dearation valve.

Refilling
Press red button of the deaeration valve and keep depressed until complete pressure relief; monitor pressure relief on pressure gauge.

• Dismount air pump.
• Fill in lubricant, remount pump and screw fast.
• Actuate air pump again to build up pressure cushion.
