Description
Klüberfluid C-F 3 M Ultra Operational lubricant for large girth gear drives | N° 039088
- Klüberfluid C-F 3 M ULTRA is a newly developed transparent adhesive lubricant especially for the lubrication of medium-size to large girth gear drives. It is based on a mixture of synthetic hydrocarbons and mineral oil.
- Klüberfluid C-F 3 M ULTRA provides extremely good adhesion, resistance to high pressure and exceptional wear protection. It is suitable for use at component temperatures up to 120 °C.
- Klüberfluid C-F 3 M ULTRA is free from bitumen, solvents, heavy metals, chlorine and solid lubricants. Klüberfluid C-F 3 M ULTRA corresponds to ANSI/AGMA 9005-E02 annex D-2.
- Volume: 25 kg bucket
- Also available in: 180 kg barrel
Benefits for your application
- Operational lubricant for open drives; spray or manual application
- For elevated component and ambient temperatures
- Free from heavy metals, chlorine, solvents, bitumen and solids
- Very good adhesion
- Easy application
- Optimum wear and tooth flank protection
- Low maintenance, lower disposal costs
- Light-colored, transparent product
Applications
- Klüberfluid C-F 3 M ULTRA is primarily used for the lubrication of rather large gear-rim/pinion drives. It can be used with all gear sizes
and power ratings. A peripheral speed of 12 m/s should however not be exceeded. - Klüberfluid C-F 3 M ULTRA was especially developed for ships and the offshore sector, where most of such drives are found. However, application is also in other industries
Application notes
- Klüberfluid C-F 3 M ULTRA can be applied to the tooth flanks by means of spray lubrication systems working with container or barrel pumps. For pumping, the lubricant temperature should be > 25 °C. Klüberfluid C-F 3 M ULTRA can also be applied by brush or spatula. The lubricant film on the tooth flanks can be made visible by using a UV lamp of at least 366 nm.
Technical specifications
| Manufacturer number | 0390880177 |
| Colour space | brown |
| Texture | homogeneous |
| Application, in automatic spray systems | 25 – 100 °C |
| Functional lubricant film | approx. 0 °C |
| Thermal stability of the lubricating film, depends on the relubrication | ≤ 120 °C |
| Density, DIN 51757, 20°C | approx. 0.95 g/cm³ |
| Flash point, DIN EN ISO 2592, Cleveland open cup | ≥ 200 °C |
| Kinematic viscosity, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 100°C | approx. 750 mm²/s |
| Kinematic viscosity, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 40°C | approx. 25500 mm²/s |
| Viscosity index, DIN ISO 2909 | approx. 185 |
| Pour point, DIN ISO 3016 | ≤ 10 °C |
Klüberfluid C-F 3M Ultra, Klüberfluid C-F3M Ultra, Klüberfluid CF 3M Ultra
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
