Description
Klüberbeta VR 67-17002 Special soft grease for sanitary and heating valves and taps
- A pasty, whitish special grease for valves and fittings.
- It is based on silicone oils which comply with drinking water regulations. It shows a high dynamic viscosity which is relatively insensitive to temperature.
- Klüberbeta VR 67-17002 is a thixotrope product, i.e. it behaves like a consistent lubricant when at rest, while under dynamic load it begins to flow.
- The product thus combines sufficient wetting of the friction point and hence sound lubrication with a good sealing effect and adhesion.
- The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries.
- Temperature range: -40°C to +160°C
- Volume: Can 1 kg
- Also available in: Bucket 25 kg
Benefits for your application
Prolonged service life of cartridges, valves and fittings due to
- continuous wetting of the friction surfaces
- compatibility with most standard elastomers and plastics
- friction and wear reduction in most material combinations
Prevents stick-slip and provides balanced damping of operation
- as temperature has little effect on lubricating film thickness
- due to high base oil viscosity (effect on actuating forces)
Certified for use in drinking water and beverage taps
- according to UBA (German Environmental Agency) guideline BWGL-KTW, NSF/ANSI/CAN 61, WRAS, ACS, Belgaqua, AS 4020, NSF H1 – further certifications available on request
NSF ISO 21469 certified – supports the compliance with the hygienic requirements in your production plant.
Applications
- Klüberbeta VR 67-17002 is suitable for drinking water and beverage taps as well as in heating installations, for example to improve the smooth operation of valves and fittings through defined actuating forces.
- Typical applications include the lubrication of ceramic discs, e.g. in single lever mixer taps, piston mixers, plastic taps, valves, thermostats, press fit seals and similar components.
- Klüberbeta VR 67-17002 has proven particularly successful as assembly lubricant for seals, collars and seal packings in cold and hot water as well as steam applications.
Application notes
- Being a silicone grease, Klüberbeta VR 67-17002 shows mostly neutral behaviour towards most metals, thermoplastics and elastomers.
Technical specifications
| Article number | 022225 |
| NSF-H1 registration | 144 019 |
| Colour space | white |
| Chemical composition, type of oil | silicone oil |
| Chemical composition, thickener | silicate |
| Lower service temperature | -40 °C / -40 °F |
| Upper service temperature | 160 °C / 320 °F |
| Density at 20 °C | approx. 1.05 g/cm³ |
| Unworked penetration, acc. to Klein, 25 °C, lower limit value | 240 x 0.1 mm |
| Unworked penetration, acc. to Klein, 25 °C, upper limit value | 300 x 0.1 mm |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 20 000 mPas |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 46 000 mPas |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 25 °C | approx. 17 000 mm²/s |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 12 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
