Description
UNIMOLY HTC METALLIC High-temperature paste containing graphite and metal | N° 011055
- UNIMOLY HTC METALLIC is a high-temperature lubricating and assembly paste containing graphite and metal. It has a chemical composition of mineral oil, lithium soap and a solid lubricant mixture.
- Above a temperature of 150 °C the base oil evaporates and leaves a dry lubricating film. The paste contains no lead, nickel, sulphur, barium and halogens.
- Temperature range: -25°C to +1200°C
- Volume: 600g can
Benefits for your application
- Ensures easy disassembly even after the influence of high temperatures
- High pressure absorption capacity
- Prevents stick slip
- Meets the requirements set forth by automobile manufacturers
- Also available as spray (UNIMOLY HTC METALLIC Spray, art. No. 081047)
Applications
- UNIMOLY HTC METALLIC is suitable as a high-temperature paste for screws, nuts and bolts. The resulting dry lubricant film makes it possible to disassemble these machine elements without any problems.
- In the pressure die casting industry this paste is used for the lubrication of ejector pins, core pullers and threaded connections. In the plastic processing industry UNIMOLY HTC METALLIC is used as a lubricant for heated extruder heads and screw-on nozzles. In addition, UNIMOLY HTC METALLIC has proven effective as an assembly paste for extrusion moulding dies and as a lubricant for spring washer components.
Application notes
- NOTE: Always apply UNIMOLY HTC METALLIC in a thin layer!
- Clean the friction point with a solvent and remove all residues and separating layers, such as corrosion protection agents, to ensure optimum adhesion of UNIMOLY HTC METALLIC, then apply the paste evenly across the entire surface. In the case of machine screws make sure that the paste is also applied to the underside of the screw head.
- Only if the thread and the lower surface of the screw head are coated with the lubricant will it be possible to obtain an optimum preload force during tightening and to disassemble the parts even when they were subject to high temperatures.
Technical specifications
| Lower service temperature | 25 °C / -13 °F |
| Upper service temperature | 1200 °C / 2192 °F |
| Colour space | silver |
| Density at 20 °C | approx. 1.30 g/cm³ |
| Flow pressure of lubricating greases, DIN 51805-2, test temperature: -30 °C | <= 1 400 mbar |
| Four-ball tester, welding load, DIN 51350 pt. 04 | >= 4 000 N |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 36 months |
Hazard information (CLP)
Signal word: Warning
Hazard statements (H-phrases)
- H410: Very toxic to aquatic life with long lasting effects.
Precautionary statements (P-phrases)
Prevention:
- P273: Avoid release to the environment.
Response:
- P391: Collect spillage.
Additional labeling (EUH-phrases)
- EUH212: Warning! Hazardous dust may be released during use. Do not inhale dust.
Other relevant information
- This substance/mixture contains no components at concentrations of 0.1% or higher that are classified as PBT or vPvB.
- The substance/mixture contains no components with endocrine-disrupting properties according to REACH Article 57(f) or the EU delegated regulations.
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
