Klüber Structovis EHD Mineral oil-based special lubricant 20L canister

• STRUCTOVIS HD is a special lubricant series based on mineral oil and available in different viscosity grades.
• The STRUCTOVIS types AHD to EHD, BHD MF and BHD 75 S contain special adhesion improvers, the type BHD MF the solid lubricant MoS2 for improved emergency lubricating properties.
• STRUCTOVIS BHD 75 S contains a flammable solvent.
• All STRUCTOVIS HD types offer good wear and corrosion protection.
• The STRUCTOVIS types provided with an adhesion improver are extremely adhesive thus reducing considerably the risk of contamination due to oil leakage, especially at high
• chain speeds.
• The STRUCTOVIS types of higher viscosity (AHD to CHD) may also reduce noise of chains.
• Note: The product data of STRUCTOVIS BHD Spray and STRUCTOVIS BHD 75 S refer to the solvent-free active agent.

Application

• STRUCTOVIS HD lubricants are used for driving, control and conveyor chains. STRUCTOVIS BHD and BHD 75 S have proven particularly effective for the initial lubrication of steel link
• chains by the chain manufacturer.

Application notes

• Depending on the viscosity STRUCTOVIS HD can be applied by drip-feed or automatic lubrication systems, oil feeders or brush.
• When using automatic systems please observe the maximum viscosity specified by the manufacturer.
• If STRUCTOVIS BHD is applied by the chain manufacturer we recommend an immersion bath temperature between 80 and 90 °C.
• The low-viscosity HD types (up to 460 mm²/s at 40 °C) and BHD 75 S (please also observe safety data sheet) can also be applied in a cold-bath process.
• The chain should remain in the bath until no more air bubbles rise to the surface.
