Description
Long-term and high-temperature grease for rolling bearings
- PETAMO GHY 133 N is a high-performance lubricating grease for rolling bearings subject to high temperatures. It has the following advantages:
– Resistance to high temperatures
– High resistance to oxidation
– Efficient wear protection even at high temperatures
– Good corrosion protection
– Good water resistance - The high performance level of PETAMO GHY 133 N is achieved by means of selected product constituents such as polyurea thickener, mineral oil, synthetic hydrocarbon oil and
additives, as well as the production technology. - Content: 400g cartridge
- Available in 400g cartridge, 1kg can, 25kg bucket
Benefits
- Reduced maintenance due to lifetime lubrication
- Wide service temperature range allows a variety of applications
- Reliable operation and long service life due to excellent protection against wear and corrosion, especially in water pump bearings and clutch release bearings
Application
- PETAMO GHY 133 N is suitable for long-term and lifetime lubrication in a variety of applications including:
– Rolling bearings in
– electric motors
– fan heaters
– drying installations
– textile machines
– paper machines
– Automotive components, e.g.
– belt tensioning rollers (rotating outer ring)
– couplings
– water pumps
– fans
– wheel bearings - In component tests PETAMO GHY 133 N achieves excellent results in terms of service life.
- In water pump bearings PETAMO GHY 133 N offers excellent compatibility with coolants containing glycol.
Application notes
- PETAMO GHY 133 N can be applied by means of appropriate automatic or conventional lubrication systems in a clean working environment.
Product data
| Article number | 094061 |
| Lubricating greases -K, DIN 51825 in connection with DIN 51502 | KHC2P-30 |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Chemical composition, type of oil | mineral oil |
| Chemical composition, thickener | polyurea |
| Lower service temperature | -40 °C / -40 °F |
| Upper service temperature | 160 °C / 320 °F |
| Color space | brown |
| Density at 20 °C | approx. 0.90 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 265 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 295 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 165 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 18 mm²/s |
| Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKF-EMCOR), test duration: 1 week, distilled water |
<= 1 corrosion degree |
| Drop point, DIN ISO 2176, IP 396 | >= 250 °C |
| Flow pressure of lubricating greases, DIN 51805, test temperature: -30 °C | <= 1 400 mbar |
| Testing of lubricating greases on FAG FE9 rolling bearing tester, DIN 51821 pt. 02, speed:6000 min-1, axial load:1500 N, temperature: 160 °C, service life F50: |
>= 100 h |
| Low-temperature torque, IP 186, -40 °C, running | <= 250 mNm |
| Low-temperature torque, IP 186, -40 °C, start | <= 1 000 mNm |
| Speed factor (n x dm) | approx. 500 000 mm/min |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. |
24 months |
Hazard statements (CLP)
Signal word: Warning
Hazard statements (H-phrases)
- H410: Very toxic to aquatic life with long lasting effects.
Safety precautions (P-phrases)
Prevention:
- P273: Avoid release to the environment.
Response:
- P391: Collect spillage.
Additional labeling (EUH-phrases)
- EUH208: Contains condensation products of fatty acids, tall oil with 2-amino-2-ethylpropanediol. May cause allergic reactions.
Storage and disposal
- This substance/mixture contains components classified as persistent, bioaccumulative and toxic (PBT) or very persistent and very bioaccumulative (vPvB).
- This substance/mixture contains components identified under Article 57(f) of the REACH regulation, Commission Regulation (EU) 2018/605, or Commission Delegated Regulation (EU) 2017/2100 as endocrine-disrupting for the environment.
Other relevant information
- This substance/mixture contains no components with endocrine-disrupting properties according to REACH Article 57(f) or Commission Delegated Regulation (EU) 2017/2100 or 2018/605 in concentrations of 0.1% or more.
Klüber Petamo GHY133N, Petamo GHY 133N, GHY-133-N, GHY-133 N
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
