Description
NONTROP RB 3 DIN E Grease for propane, butane, natural and town gas valves and fittings | N° 001045
- NONTROP RB 3 DIN E is a thermally stable lubricating, sliding and sealing agent based on mineral oil and thickened with a thermally very stable silicate and solid lubricant.
- Temperature range: -10°C to +140°C
- Volume: Can 1 kg
- Also available in: Bucket 25 kg
Benefits for your application
- Tested and approved by DVGW acc. to DIN EN 377 class D
- Very good and durable wetting of friction points
- Neutral towards copper and its alloys
- High thermal stability
- Neutral towards DIN EN 377 elastomers, e.g. SRE-NBR 1
- Contains solid lubricant to compensate for roughness peaks and areas subject to elevated load
Applications
- NONTROP RB 3 DIN E is used as lubricant, sliding and sealing agent in gas equipment of all categories including the additional fittings contained in them or intended to be fitted in them which can come into contact with fuel gases.
- Such fittings include ball, taper plug and other valves in cooking and heating installations, etc., with an operating temperature from 0 °C to 140 °C
Application notes
- Carefully clean and degrease the friction points prior to initial lubrication. Then apply a thin and uniform layer of NONTROP RB 3 DIN E by means of brush, spatula or suitable metering system to all friction points of the component.
Technical specifications
| Chemical composition, solid lubricant | solid lubricant |
| Chemical composition, solid lubricant | silicate |
| Chemical composition, type of oil | mineral oil |
| Colour space | black |
| Texture | homogeneous |
| Density at 20 °C | approx. 1.10 g/cm³ |
| Drop point, DIN ISO 2176, IP 396 | >= 240 °C |
| Copper corrosion, DIN 51811, (lubricating grease), 24h/140°C | <= 2 – 140 corrosion degree |
| Oil separation, ASTM D 6184 [FTMS 791 C 321], after 30 h/100 °C | <= 1 % by weight |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 11 500 mPas |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 7 500 mPas |
| Lower service temperature | -10 °C / 14 °F |
| Upper service temperature | 140 °C / 284 °F |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
