Description
Adhesive dampening greases of medium to high shear viscosity.
- CATENERA KSB 6, 8, 12 are adhesive dampening greases based on synthetic hydrocarbon, ester and paraffin oil. They contain silicate as thickener.
- In the food and pharmaceuticals industries, CATENERA KSB 8 may be preferably used for applications where technically unavoidable contact with the food product cannot be excluded.
- CATENERA KSB 8 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of CATENERA KSB 8 can contribute to increase reliability of your production processes.
- We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.
- Content: 1kg can
- Available in 50g tube, 400g cartridge, 1kg can, 25kg bucket
Benefits for your application:
- More comfortable operation (haptics) of mechanical components as friction points are dampened by the lubricant
- Better component function e.g. due to good adhesion retaining the lubricant at the friction point
- CATENERA KSB 8 is certified according to NSF ISO 21469, supporting the compliance with the hygienic requirements in your production.
Application:
- CATENERA KSB greases are used for friction points requiring high mechanical dampening and good adhesion, e.g. low-speed rolling and plain bearings, small gears, threaded spindles, eyepieces and binoculars.
- CATENERA KSB is available in three shear viscosity grades in order to meet dampening and adhesion requirements.
- For even higher shear viscosities we refer to the Klübersynth RA greases.
Application notes:
- CATENERA KSB greases can be applied by brush, spatula, grease gun, automatic metering systems for small quantities, grease cartridge and the usual metering systems. Owing to the many different elastomer and plastic compositions their compatibility has to be checked prior to series application.
Product data:
| Article number | 007003 |
| NSF-H1 registration | 113 755 |
| Chemical composition, type of oil | paraffinic mineral oil |
| Chemical composition, type of oil | ester oil |
| Chemical composition, thickener | silicate |
| Lower service temperature | -30 °C / -22 °F |
| Upper service temperature | 120 °C / 248 °F |
| Color space | beige |
| Texture | fibrous |
| Texture | homogeneous |
| Appearance | almost transparent |
| Density at 20 °C | approx. 0.93 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 260 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 300 x 0.1 mm |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value |
6 000 mPas |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value |
10 000 mPas |
| Minimum shelf life from the date of manufacture – in a dry, frostfree place and in the unopened original container, approx. |
12 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
