Description
Divinol SynthoHyd Eco 46 is a fully synthetic, biodegradable multigrade hydraulic fluid based on PAO (HVLP / HEPR ISO VG 46) with zinc- and ash-free additive technology. Ideal for environmentally demanding hydraulic systems.
- Pack size: 20 L canister
- Also available in: 60 L drum, 200 L drum
Applications
- Mobile hydraulics in forestry, construction, and transport machinery
- Outdoor stationary systems: sluices, scrap presses, loading units
- Indoor equipment such as injection molding machines
- Year-round use under extreme temperature conditions
Approvals and Recommendations
- DIN 51524-3 (HVLP)
- ISO 15380 – HEPR
- EU Ecolabel (DE/027/268), Austrian Ecolabel
- Swedish Standard SS 155434
- Caterpillar BF1/BF2, Liebherr, Palfinger
- Komatsu BO 46 G4, HO56-HE
- Parker Denison HF-0, HF-1, HF-2
- EATON E-FDGN-TB-002-E, Brochure 03-401-2010
- Engel, KraussMaffei
Features
- Biodegradable > 60 % according to OECD 301
- Zinc- and ash-free additive technology
- Outstanding oxidation stability and long service life
- Excellent low and high temperature behavior (-39 °C to >230 °C)
- Compatible with mineral oil and ester-based fluids
- Suitable for extended oil change intervals
Technical Data
| Physical Properties | |
|---|---|
| Appearance / Color | yellowish, clear |
| Density (15 °C) | 0.84 g/cm³ (DIN EN ISO 12185) |
| Viscosity (40 °C) | 46 mm²/s (ASTM D7042) |
| Viscosity (100 °C) | 8 mm²/s (ASTM D7042) |
| Viscosity Index | > 155 (ASTM D2270) |
| Pour point | -39 °C (ASTM D7346) |
| Flash point | > 230 °C (DIN ISO 2592) |
| Biodegradability | > 60 % (OECD 301) |
| Copper corrosion | grade 1a (DIN EN ISO 2160) |
| FZG test A/8.3/90 | Load stage 14 (DIN 51354/2) |
Notes
- When converting from mineral oil to Divinol SynthoHyd Eco 46, follow VDMA 24569 and the equipment manufacturer’s guidelines.
- Compatible with PAO- and ester-based biofluids and with conventional mineral oils.
Zeller+Gmelin GmbH & Co. KG, Schlossstrasse 20, 73054 Eislingen/Fils, GERMANY, +49 7161 802-0, [email protected], www.zeller-gmelin.de
