Description
Divinol ICL ISO 100 is a zinc-free CLP high-pressure gear oil (ISO VG 100) for use in heavily loaded gears.
- Pack size: 20L canister
Applications
- For use in heavily loaded gears with circulation lubrication, as well as bath-lubricated gears with spur and bevel gears, and worm gears.
Specifications
- DIN 51 517 Part 3, CLP
- ISO 12925-1 – CKC, CKD
- AISE 224, AGMA 9005-E02, and David Brown S1.53.101 (E)
Features
- Industrial high-pressure gear oil
- Zinc-free
- High load-carrying capacity
- Contains phosphorus- and sulfur-based EP/AW additives
- Reduces friction and protects against wear
- Excellent aging and temperature stability
- Outstanding demulsifying properties
- Good corrosion protection
- Contains foam regulators to reduce foam formation
Technical specifications
| Manufacturer Number | 25040-K030 |
| Colour / DIN ISO 2049 | lighter 3.0 |
| Density/15°C / DIN EN ISO 12185 | 890 kg/m³ |
| Viscosity/40°C / ASTM D 7042 | 100 mm²/s |
| Flash point (Cleveland) / DIN ISO 2592 | > 210 °C |
| Pour point / ASTM D 7346 | ≤ -12 °C |
| Corrosion protection towards steel / DIN ISO 7120-A | Corrosion degree 0 |
| Corrosion effect on copper / DIN EN ISO 2160 | Corrosion degree max. 1 |
| Loading capacity according to Brugger / DIN 51 347 | 65 N/mm² |
| FZG test A/8.3/90 / DIN 51 354/2 | Damage loading step > 12 |
Zeller+Gmelin GmbH & Co. KG, Schlossstrasse 20, 73054 Eislingen/Fils, GERMANY, +49 7161 802-0, [email protected], www.zeller-gmelin.de
