Castrol Tribol GR 3020/1000-0 PD High performance grease NLGI-0 18kg

Application

• Typical applications for Tribol GR 3020/1000 PD fluid greases (NLGI 0,00,000) are non-oil-tight gear units, rolling and sliding bearings, bushings, slides and general lubrication designed for fluid-grease lubrication
• Large slow-speed bearings where the Tribol 3020/1000 PD greases provide a sufficient lubricating film due to their high base oil viscosity
• Tribol GR 3020/1000 PD grease (NLGI 1 &2) can be used for roller and sliding bearings, spindles, power train couplings (with exception to high speed precision couplings), carriages, cams and common grease points.
• They’re commonly used in the steel, mineral compound, construction and mining industry
• Operating temperatures range from -40°C to +120°C/ -40°F and +248°F

Advantages

• Excellent pumpability in central lubrication systems
• Repairs damaged friction surfaces (roughness) due to the TGOA additives
• Extends lubrication interval
• Reduces wear and noise
• Lowers operating temperatures
• Lowers downtime, therefore reducing maintenance and repair costs
• Optimum sealing effect, due to excellent adhesion of the grease

Technical specifications

• Appearance: Homogeneous
• Thickener type: Lithium
• Base Oil: Mineral Oil
• Consistency NLGI Grade: 0
• Worked Penetration (60 strokes @ 25°C / 77°F) 0.1 mm: 355 – 385
• Base Oil Viscosity @ 40°C / 104°F mm²/s: >700
• Base Oil Viscosity @ 100°C / 212°F mm²/s: 54
• Rust Test (distilled water) Rating: Pass
• Volume: 18kg bucket
• Also available in: 400g cartridge, 5kg bucket, 50kg barrel, 180kg barrel
• GLIS number: 1576B5
• MSDS code: 468587

Description ​Castrol Tribol™ GR 3020/1000 PD series

Castrol Tribol™ GR 3020/1000 PD (previously called Tribol 3020/1000) is a range of greases formulated from highly
refined petroleum base oils, a lithium thickener, and Tribol Grease Oil Additive (TGOA). The TGOA additive package
outperforms all other Extreme Pressure (EP) and Anti-Wear (AW) additives because of its unique action on frictional
surfaces.
The base oils are high-viscosity mineral oils forming a stable lubricant film to withstand high continuous loads, shock
loads and vibrations. The TGOA additive package is activated by high specific loads and corresponding temperatures
causing a chemical physical reaction. This results in an equalisation of surface roughness without creating abrasion.
The results of the TGOA additives can be compared with a rolling process in the micro-range. The surface roughnesses
are gradually leveled and smoothed. In smoothing the working surfaces, the loads are distributed over increasing areas
and the actual load carrying areas are enlarged. During the running-in process, the TGOA additive package creates an
optimum of smooth contact surfaces. If, because of shock loads, or stop-and-go operation, surface roughness peaks
redevelop, the TGOA additives are automatically reactivated. Surface roughness is again equalised and lubrication
optimised. Corrosion and oxidation inhibitors help maximise effective rust protection and long life of the grease.
The Tribol GR 3020/1000 PD Range contains NLGI consistency grades commonly available for these types of
lubricants.
Castrol Tribol GR 3020 1000-0 PD, Castrol Tribol GR 3020/1000 0 PD, Castrol Tribol GR3020/1000-0 PD
