Castrol Spheerol CLX 2 Water resistant grease NLGI 2 400g cartridge

Spheerol CLX 2 is a complex calcium grease (NLGI 2) with good water resistance and high load carrying capacity. Spheerol CLX 2 is based on highly refined mineral oil and combined with carefully selected additives to provide excellent chemical and thermal stability. Spheerol CLX 2 contains no lead-based components.

• Volume: 400 g cartridge
• Also available in: 18 kg bucket, 50 kg barrel

Application

Spheerol CLX 2 is used for the lubrication of plain bearings and

ball bearings in the steel industry such as bearings and rollers of conveyor guides in hot rolling mills or in cement plants for the lubrication of rotating hearths.
Spheerol CLX 2 can also be used in the paper and glass industries when the ambient temperature is very high. Spheerol CLX 2 resists drying even after a long period of exposure to high temperatures. Its normal operating temperature ranges from -20°C to +140°C.
The maximum operating temperature is +180°C with more frequent lubrication. Spheerol CLX 2 should not be mixed with other greases!

Advantages

• Good water resistance
• Excellent mechanical stability
• Resistant to high loads
• Resistant to oxidation
• Good resistance to radiation drying
• Good pumpability
• Formulated for use in centralized lubrication systems

Technical specifications

• Type: calcium complex
• Grade NLGI ISO 2137: 2
• Texture / Colour: smooth / brown
• Operating temperature range: -20°C to +140°C
• Drop point ASTM D 566 °C: > 300
• Base oil viscosity at 40°C ISO 3105 mm2/s: 145
• Worked penetration 25°C / 60 strokes ISO 2137 0,1 mm: 275/295
• Worked penetration 25°C / 100000 strokes ISO 2137 0,1 mm: +50
• GLIS number: 1599A9
• MSDS code: 467061
