Castrol Molub-Alloy CH 22 Multi-purpose chain oil for wire ropes 20L

Castrol Molub-Alloy CH 22 Multi-purpose chain oil for wire ropes ISO VG 22

Castrol Molub-Alloy™ CH Chain Oils (previously called Castrol Molub-Alloy™ Chain Oil) are multi-purpose chain lubricants designed for use in a variety of plant-wide chain applications. These lubricants are manufactured from a combination of the highest quality components including, antiwear/ extreme pressure additive system with advanced Molub-Alloy lubricating solids. They are also compounded to inhibit oxidation and to protect against rust and corrosion.

Application

Molub-Alloy CH 22 is an excellent lubricant for wire ropes, especially those with a sisal or polypropylene core. It is highly inhibited to protect against rust and corrosion to protect the rope from within.

Molub-Alloy CH 100 is widely used in chain and conveyor applications where non-drip characteristics are desirable to reduce oil loss or “fling-off”. It can also be used on chains where earlier wear conditions and expanded clearances exist. Molub-Alloy 100 resists the washing action of water and detergent wash systems and offers both corrosion and wear protection in wet environments.

Molub-Alloy CH Chain Oils are used on conveyors and chains operating at temperatures up to 90°C/190°F. They can be used intermittently at higher temperatures up to 150°C/300°F but more frequent relubrication may be required.

Molub-Alloy CH Chain Oils can be applied by brush, drip, spray, mist, automatic dispensing equipment, central oiling or circulation systems.

Advantages

• Resists accumulation of contamination and abrasive matter: The semi-dry lubrication attribute of Molub-Alloy CH 22 provides a very light film, giving the appearance of a dry film. This ensures minimum pickup of abrasive dusts, lint, sand, and other particles, thus eliminating formation of abrasive compounds which can increase wear and shorten chain life.
• Excellent EP and anti-wear protection under boundary conditions: The compounded Molub-Alloy solids package provides superior protection during frequent start-up, slow speeds, and when high and/or shock loads are encountered.
• Superior friction reduction: Capable of reducing energy consumption at peak power demand during cold start-up.
• Overall savings: Savings can result from less labour and downtime, smoother, more efficient operation with longer parts life, and extended lubrication cycles.

Technical specifications

• ISO Visocity Grade: 22
• Density @ 15°C / 59°F kg/m³: 891
• Kinematic Viscosity @ 20°C / 68°F mm²/s: 59
• Kinematic Viscosity @ 40°C / 104°F mm²/s: 22
• Kinematic Viscosity @ 100°C / 212°F mm²/s: 3.9
• Flash Point – open cup method °C/°F: 170/338
• Pour Point °C/°F: -45/-49
• Volume: 20l canister
• Also available in: 208l barrel
• GLIS number: 156B89
• MSDS code: 468618

Castrol Molub-Alloy CH22, Castrol Molub Alloy CH 22, ​Castrol Molub-Alloy CH-22
