Description
Castrol Hyspin AWS 46 High-performance hydraulic oils (ISO VG 46) are based upon highly refined mineral oil enhanced with a stabilized zinc additive system. Ideal for hydraulic systems with increased wear protection requirements.
- Size: 208 l barrel
- Also available in: 20 l canister
Application
- For use in industrial hydraulic systems which require antiwear protection
- Lightly loaded gears, variable speed units and bearings
- Compatible with the most commonly used nitrile, silicone and fluropolymer seal materials.
Specifications / Approvals
- DIN 51524-2 – Requirements for HLP hydraulic oils
- ISO 6743/4 Requirements for HM hydraulic oils
Advantages
- Good thermal and oxidative stability. Oxidative stability reduces deposit formation, resulting in a cleaner system. This can extend the machinery’s operating life.
- Excellent anti-wear performance increases wear protection, which can help reduce downtime caused by unscheduled maintenance.
- Good filterability characteristics, including in the presence of water, enables cost savings to be made from increased filter life and reduced maintenance.
- Excellent water separation and hydrolytic stability, measured by industry standard testing. This increases equipment reliability, helping to prolong the lubricant’s life and reduce downtime.
Technical specifications
| GLISS number | 15FE18 (15F040) |
| MSDS code | 456617 |
| ISO Viscosity Grade | 46 |
| Density at 15°C, kg/m³ | 880 |
| Kinematic Viscosity at 40°C, mm²/s | 46 |
| Kinematic Viscosity at 100°C, mm²/s | 6.7 |
| Flash Point – open cup method, °C | 215 |
| Flash Point – closed cup method, °C | 200 |
| Pour Point, °C | -24 |
Description Hyspin AWS range
Hyspin AWS has been specially formulated to provide good anti-wear and thermal stability performance using proven additive technology. The careful blend of additives with a high quality base stock ensures that Hyspin AWS has excellent hydrolytic and oxidative stability while exhibiting a minimal tendency to produce sludge and deposits. In addition, Hyspin AWS provides corrosion protection to ferrous and yellow metal components found within a hydraulic system.
Hyspin AWS (for appropriate viscosity grade) is approved by:
- Parker Hannifin (Denison) HF0, HF1 & HF2
- Eaton E-FDGN-TB002-E
Hyspin AWS grades meet the requirements (for appropriate viscosity grade) of:
- DIN 51524 Part 2
- Fives Cincinnati P68, P69 & P70
- ASTM D6158 HM
- ISO 11158 HM
- US Steel 126
- GB 11118.1 L-HM (General and High Pressure)
BP Europa SE, Erkelenzer Straße 20, 41179 Mönchengladbach, GERMANY, +49 800 7235 074, [email protected], www.bp.com
