Description
- A 2-part composite material for metal repair and resurfacing based on a 100% solids, surface-tolerant epoxy resin reinforced with silicon steel alloy.
- This composite material is specifically designed for application to wet and oil contaminated surfaces, as well as for underwater applications.
- It is easy to mix and apply without the need of specialist tools and can be machined using conventional tools.
Applications
- Repair of oil and water leaks
- Sealing of joints and flanges
- Repair of cracks and holes on engine and pump casings, transformers, pipes, tanks and other equipment
- Resurface of pitted metal surfaces
- High strength structural adhesive for metal bonding
- Creation of irregular load bearing shims and reforming of bearing housings
- Application should ideally occur in the following ambient temperature range: 5°C to 40°C
- The volume capacity of mixed material is 428 cm3 (26.1 in3)/kg.
Characteristics
- Bonds strongly to wet, oily and manually prepared surfaces
- Multi-purpose durable repair composite
- Application and cure at room temperature and underwater – no hot work involved
- Excellent bonding to metals including stainless steel, carbon steel, aluminium, brass, copper and other rigid surfaces
- Fully machinable using conventional tools
- Excellent electrical insulation characteristics
- Reduced health and safety risks as it is 100% solids
- No shrinkage, expansion or distortion
- Outstanding corrosion protection
- Excellent chemical resistance against a wide range of chemicals
Technical specifications
| Base Component | |
| Colour | Dark Grey |
| Form | Paste |
| Density | 2.80 g/cm3 |
| Gel Strength (HF paddle) | >150 g/cm |
| Solidifier Component | |
| Colour | Light Grey |
| Form | Paste |
| Density | 1.40 g/cm3 |
| Gel Strength (QV paddle) | 90 g/cm |
| Mixed Properties | |
| Mixing Ratio by Weight (Base : Solidifier) | 4 : 1 |
| Mixing Ratio by Volume (Base : Solidifier) | 2 : 1 |
| Colour | Grey |
| Mixed Form | Paste |
| Mixed Density | 2.34 g/cm3 |
| Slump Resistance | >0.5 in / >12.7 mm |
| VOC (ASTM D2369) | 0.10 % / 2.39 g/L |
Hazard Information (CLP)
Signal word: Warning
Hazard Statements (H-phrases)
- H315: Causes skin irritation.
- H317: May cause an allergic skin reaction.
- H319: Causes serious eye irritation.
- H411: Toxic to aquatic life with long lasting effects.
Precautionary Statements (P-phrases)
Prevention:
- P273: Avoid release to the environment.
- P280: Wear protective gloves, clothing and eye protection.
Disposal:
- P501: Dispose of contents/container in accordance with local regulations.
Other relevant information
- Contains: Phenol Novolac Epoxy Resin, Epoxy resins (average molecular weight ≤ 700).
