Description
Product Details
Advance Tapes Copper Tapes
The Advance Tapes copper tape is a 35μ, coated with conductive acrylic adhesive supplied on a removable silicon liner. This tape is 0.06mm thick, 25mm wide and 33m long.
EMI/RFI shielding tapes:
When using this tape, galvanic compatibility should be taken into account.
EMI/RFI shielding tapes:
When using this tape, galvanic compatibility should be taken into account.
Features and Benefits
Good high and low temperature resistance
Easy unwind
Can be easily soldered
Superior shielding effectiveness
Breaking load is 40N/cm
Operating temperature ranges between -20°C and 155°C
Easy unwind
Can be easily soldered
Superior shielding effectiveness
Breaking load is 40N/cm
Operating temperature ranges between -20°C and 155°C
Applications
Heating and ventilation
Construction industry
Manufacturing
Duct sealing
Construction industry
Manufacturing
Duct sealing
Specifications
| Total Thickness | 0.06mm |
|---|---|
| Tape Type | Copper Tape |
| Foil Thickness | 0.035mm |
| Width | 25mm |
| Length | 33m |
| Conductivity | Conductive |
| Adhesion Strength | 4.5 N/cm |
| Adhesive Material | Thermosetting Acrylic |
| Material Plating | None |
| Tensile Strength | 40N/cm |
| Maximum Temperature Resistance | +155°C |
| Complies with EN Legislation | BS EN 60454 – Part 2 |
| Minimum Temperature Resistance | -20°C |
| Model Number | AT526 |
