Advance Tapes Copper Tapes
The Advance Tapes copper tape is a 35μ, coated with a non-conductive acrylic adhesive, supplied on a removable silicon liner. This tape is 0.07mm thick, 19mm wide and 33m long.
Note:
To prevent tarnishing, do not touch this tape with bare hands.
EMI/RFI shielding tapes:
When using this tape, galvanic compatibility should be taken into account.
Note:
To prevent tarnishing, do not touch this tape with bare hands.
EMI/RFI shielding tapes:
When using this tape, galvanic compatibility should be taken into account.
Features and Benefits
Adhesion strength is 4.5N/cm
Good high and low temperature resistance
Can be easily soldered
Easy unwind
Breaking load is 40N/cm
Provides superior shielding effectiveness
Operating temperature ranges between -20°C and 155°C
Applications
Heating and ventilation
Construction industry
Manufacturing
Duct sealing
Construction industry
Manufacturing
Duct sealing
Specifications
| Tape Type | Copper Tape |
|---|---|
| Total Thickness | 0.07mm |
| Foil Thickness | 0.035mm |
| Width | 19mm |
| Length | 33m |
| Conductivity | Non-Conductive |
| Adhesion Strength | 4.5 N/cm |
| Adhesive Material | Thermosetting Acrylic |
| Material Plating | None |
| Tensile Strength | 40N/cm |
| Maximum Temperature Resistance | +155°C |
| Minimum Temperature Resistance | -20°C |
| Complies with EN Legislation | BS EN 60454 – Part 2 |
| Model Number | AT525 |
